Full HD image quality
2 MP CMOS image sensor delivers clear 1920 × 1080 resolution video at frame rates up to 30 frames per second. Progressive scanning helps maintain smooth image during motion detection.
Wide 2.8 mm viewing angle
Fixed focus 2.8 mm lens provides 103° horizontal, 55° vertical and 123° diagonal viewing angle. Wide coverage is suitable for monitoring yards, entrances, shops and other areas.
Motorised camera control
Camera can be rotated horizontally from 0° to 345° and tilted vertically from 0° to 90°. 50 preset positions available, position memory after power loss and automatic return to home position.
Smart dual illumination
Built-in infrared and warm white LED illumination provides visibility up to 30 m. Camera can automatically adjust illumination to capture black and white or colour image in darkness according to monitoring situation.
Active deterrence
Upon detecting a security event, camera can activate flashing warm white light warning and audio alert. Flashing duration can be set from 5 to 30 seconds, while audio volume and repeat count can be customised to user requirements.
Human and vehicle detection
Smart analytics functions detect humans and vehicles, helping reduce false alarm notifications caused by insignificant moving objects. Camera also supports smart perimeter protection.
Two-way voice communication
Built-in microphone enables audio recording, while built-in speaker allows real-time two-way voice communication and playback of alert notifications.
Clear image in complex lighting
120 dB wide dynamic range, backlight compensation, bright light compensation, electronic fog reduction and 2D and 3D noise reduction help maintain clear image in uneven lighting conditions.
Efficient video compression
Smart H.265+, H.265, Smart H.264+ and H.264 video compression technologies reduce network load and storage space required for recordings. Camera simultaneously provides two video streams.
Remote management
Camera can be remotely managed and viewed from iOS and Android mobile devices. It supports ONVIF profiles S and T, as well as up to 20 users with total network bandwidth up to 64 Mbit/s.
Power over single network cable
PoE technology provides camera power and data transmission over a single Ethernet cable. Camera can also be operated with 12 V DC power source.
Durable outdoor housing
IP66 protection rating protects camera from dust and powerful water jets. Camera is equipped with 2000 V lightning surge protection and designed for operation at temperatures from −30 °C to +55 °C.
Specification
Product code: 1449797
Model: IPC-PT1239H-PV-0280B
Manufacturer model: IPC-PT1239H-PV-0280B
EAN: 6939554980299
Camera type: motorised dome IP security camera
Installation location: indoors and outdoors
Connection type: wired
Colour: white
Image sensor: CMOS
Resolution: 2 MP
Maximum resolution: 1920 × 1080
Maximum frame rate: 30 frames/s
Built-in memory: 128 MB
RAM: 128 MB
Scanning system: progressive
Electronic shutter speed: 1 to 1/30 000 s
Minimum illumination in colour mode: 0.05 lx
Minimum illumination in black and white mode: 0.005 lx
Minimum illumination with illuminator on: 0 lx
Signal to noise ratio: at least 55 dB
Lens type: fixed focus lens
Focal length: 2.8 mm
Maximum aperture: F1.6
Aperture control: fixed
Horizontal viewing angle: 103°
Vertical viewing angle: 55°
Diagonal viewing angle: 123°
Minimum focusing distance: 0.8 m
Detection distance: 38.6 m
Observation distance: 15.4 m
Recognition distance: 7.7 m
Identification distance: 3.86 m
Pan range: 0°–345°
Tilt range: 0°–90°
Manual pan speed: 0.1–37.66°/s
Manual tilt speed: 0.1–32.61°/s
Preset pan speed: 0.1–37.19°/s
Preset tilt speed: 0.1–30.82°/s
Number of preset positions: 50
Memory after power loss: yes
Automatic return to home position: yes
PTZ control lock: yes
Illumination type: infrared and warm white LED
Infrared illumination distance: up to 30 m
Warm white light distance: up to 30 m
Number of illuminators: 2
Illumination control: automatic, manual or off
Smart dual illumination: yes
Day and night mode: automatic, colour or black and white
Active deterrence: light and audio warning
Light warning: flashing warm white light
Light warning duration: 5–30 s
Light flashing frequency: high, medium or low
Custom audio notification import: yes
Audio volume adjustment: 0–100 %
Audio repeat count: 1–10
Smart video analytics: yes
Human detection: yes
Vehicle detection: yes
Perimeter protection: yes
Video compression: Smart H.265+, H.265, Smart H.264+, H.264B, H.264M, H.264H and MJPEG
Number of video streams: 2
Main video stream resolution: up to 1920 × 1080
Secondary video stream resolution: up to 640 × 360
Video bitrate in H.264 format: 16–8192 kbit/s
Video bitrate in H.265 format: 6–6400 kbit/s
Bitrate control: CBR and VBR
Wide dynamic range: 120 dB
Noise reduction: 2D and 3D
Backlight compensation: yes
Bright light compensation: yes
Electronic fog reduction: yes
Motion detection: yes
Interest areas: yes
Privacy masks: 4 zones
Image rotation: 180°
Built-in microphone: yes
Built-in speaker: yes
Two-way voice communication: yes
Audio compression: PCM, G.711A, G.711Mu and G.726
Abnormal sound detection: yes
Alarm responses: image capture, preset position activation, recording, audio alert and email notification
Alarm events: motion detection, video masking, audio detection, network disconnection and IP address conflict
Recording storage: FTP
Network connection: RJ-45, 10/100 Base-T
Network protocols: HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, DHCP, DNS, DDNS, SSL, ARP, RTCP and RTP
Compatibility: ONVIF profiles S and T; CGI; SDK
Data transmission type: unicast and multicast transmission
Maximum number of users: 20
Total network bandwidth: 64 Mbit/s
Mobile operating systems: iOS and Android
Management software: SmartPSS, DMSS, Player, ConfigTool, NVR and Smart Player
Power supply: 12 V DC or PoE
PoE standard: IEEE 802.3af
Basic power consumption with 12 V supply: 3 W
Maximum power consumption with 12 V supply: 11 W
Basic power consumption with PoE: 4 W
Maximum power consumption with PoE: 12 W
Power adapter included: no
Operating temperature: from −30 °C to +55 °C
Operating humidity: up to 95 %
Protection rating: IP66
Surge protection: 2000 V
Dimensions: 128.4 × Ø127.3 mm
Net weight: 410 g
Gross weight: 500 g
